Trumpf Trumatic L3020 Laser Cutting Machine

Show in original language

This Trumpf Trumatic L3020 Laser Cutting Machine, made in Germany in 2005, has a working record of around 32000 production hours. Equipped with a SIEMENS SINUMERIK 840D Control unit, this well maintained machine has mainly worked with 4 mm steel sheets during the past and comes with a nozzle and software included.

Overview

brand: TRUMPF
year: 2005
MODEL: Trumatic L3020
production hours: 32000
application type: Cutting
Location: India
machine type: CO2 Laser Cutting Machine
availability: Sold

Technical Information - TRUMPF Trumatic L3020

General Data

Measurements width: 4600 mm
Measurements depth: 9300 mm
Measurements height: 2000 mm
Machine weight: 10500 kg

Control Unit

Brand: SIEMENS
Model: SINUMERIK 840D

Main drive

Laserpower: 3.2 kW
Laser type: CO2
Laser brand: Trumpf

Movement

X-AXIS Movement: 3000 mm
Y-AXIS Movement: 1500 mm
Z-AXIS Movement: 115 mm

Max Material thickness

Steel: 15 mm
Stainless steel: 10 mm
Aluminum: 3 mm

Media

Main electronic connection: 415 V / 50 Hz
Power consumption: 73 kVA
Internal cooling: Yes

Additional Equipment

- Nozzle
- Software

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
