Hembrug Mikroturn 300 Base Line Lathe

Show in original language

This Hembrug Mikroturn 300 Base Line Lathe was built in Czech Republic in 2014. It has been working for 9641 hours. It is equipped with a Fanuc 0i-TD control unit. This machine can works with a spindle speed range up to 4000 rpm. Very good condition.

Overview

brand: Hembrug
year: 2014
MODEL: Mikroturn 300 Base Line
application type: Turning
Location: Czech Republic
machine type: Horizontal Turning Machine
availability: Sold
control unit brand: FANUC

Technical Information - Hembrug Mikroturn 300 Base Line

General Data

Measurements width: 2980 mm
Measurements depth: 1900 mm
Measurements height: 2040 mm
Machine weight: 6500 kg

Control Unit

Model: 0i-TD
Brand: FANUC

Main drive

Number of spindles: 1
Spindle speed range: 4000 1/MIN

Movement

X-AXIS Movement: 240 MM
Z-AXIS Movement: 350 MM

Workpiece

Workpiece weight: 100 KG

Turret

Number of turrets: 1

Tools

Slots in storage: 12
Type of tool holder: VDI-20

Media

Main electronic connection: 400 V
Power consumption: 22 kVA
Chip conveyor: Yes

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Maximum cutting diameter 350 mm
- - Main motor power 7. 5 kw
- - Max. Torque 48 nm
- - 10m/minute rapid feedrates x, z axis
- - C axis 0,001 degrees
- - Infra workpiece probe, tool probe
- - Magnetic chuck 200 mm
- - 3-jaw chuck 150 mm
- - Basic set of tools - 6 pcs
- - Tailstock with hydraulic quill
Qualitative Machine Benefits:
- - Very good condition, low hours!

Extra information

- Machine manual

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
