➤ Used Benzinger TNC-L For Sale | gindumac.com

Show in original language

This Benzinger TNC-L was manufactured in 1998. A robust horizontal turning machine featuring a max bar capacity of 26mm, main spindle drive power of 7.5kW, and a speed range up to 6500/min. It includes 35 tool holders and a coolant tank capacity of 120l. Ideal for precision turning with a swing diameter over the longitudinal slide of 380mm. If you are looking to get high-quality turning capabilities consider the Benzinger TNC-L machine we have for sale. Contact us for more information.

Overview

brand: Benzinger
year: 1998
MODEL: TNC-L
application type: Turning
Location: Germany
machine type: Horizontal Turning Machine
availability: Immediately
control unit brand: SIEMENS

Technical Information - Benzinger TNC-L

General Data

Measurements width: 1130 MM
Measurements depth: 1890 MM
Measurements height: 1800 MM
Machine weight: 1600 KG

Control Unit

Brand: SIEMENS
Model: SINUMERIK 810D

Main drive

Spindle speed range: 6500 1/MIN
Spindle motor power: 7.5 kW
Number of axis: 2

Movement

X-AXIS Movement: 300 mm
Y-AXIS Movement: 250 mm

Tools

Slots in storage: 8

Additional Equipment

- Tool Holders Included: 35

Additional Information

Machine Benefits

Technical Machine Benefits:
- - Swing diameter over longitudinal slide: 380 mm
- - Max bar capacity: 26 mm
- - Coolant tank capacity: 120 l
- - Coolant pressure at turret: 6 bar max
- - Tolerance: +6%/-10%
- - Compressed air supply: 6-8bar
- - Bore of spindle bearing: 55mm
- - Spindle nose benzinger factory standard
Qualitative Machine Benefits:
- - Accuracy according to iso tolerance 6

Extra information

- Machine still under power

*There may be differences between the data shown and the actual values, this should be confirmed by the sales representative.
